Hi, Unfortunately I can't remember what I used but it was something from Microsofts site You could have a look at this; Microsoft Global IME (Input Method Editor) 5.02 for Windows 95, 98, and NT 4.0 Microsoft Global IMEs enable the typing of Japanese, Chinese and Korean into supporting applications on other versions of Windows. International communication keeps getting easier thanks to full-featured, high-performance IMEs. You can input Chinese, Japanese, and Korean text into any Microsoft® Office XP applications, Web forms, and e-mail messages on any language version of Windows® 2000, Windows Millennium, Windows 98, Windows 95, and Windows NT® 4.0. The Global IMEs are not necessary or supported on Windows 2000 since that OS has full-featured East Asian input support built in.
Please go to the Windows Control Panel, find the Regional Options applet and do the following: 1. In the General Tab, find the 'Language Settings' area and add the language you wish to use.
This should start a copy process - you'll need your Windows 2000 CD. After the install has completed, select the 'Input Locales' tab and then add your keyboard/IME to the active list. Restart your system. Regards, Tom.
Hello, I got a drawing from overseas with Chinese text. When I open the drawing I get a message saying a font is missing. See attachment SCREENSHOT1 I contacted the sender and got the missing HZTXT.SHX font. I put the missing font in my AutoCAD font folder.
Winavi video converter serial. Download Crack WinAvi All In One Converter Crack Free Download WinAVI All-In-One Converter Full Version Crack is a professional application designed to convert the most popular video and audio formats. It can convert almost all videos and audios to play them on Continue reading. WinAVI All-In-One Converter 1.7.0.4734 http://www.mediafire.com/file/x13aeh430kq160n/WinAVI+All-In. WinAVI all in one converter Crack Download + Serial key + Registration code Full version: WinAVI all in one converter Crack is the world fastest best converter for audio along with video convers.
I open the drawing and do not get the missing font message anymore. But the text still displays as???????
I look a piece of text's properties. In the Properties dialog box the text style is shown as TSSDREIN. In the Properties dialog box the real Chinese text shows up under Contents. See attachment SCREENSHOT2 I go check out text style TSSD-REIN. It shows SHX Font = txt.shx & Big Font = hztxt.shx I have both fonts in my AutoCAD. See attachement SCREENSHOT3.
What am I missing? I'm confused. Any advice on how to get the text to display correctly? Thanks, Steve. We have AutoCAD 2015 installed on Windows 7 64-bit Chines Language Operating System. In this some drawing are showing chines text as??? But some chines text showing normal.When I convert Text to Multi Text by using TXT2MTXT command it is showing normally.
The user daily working on no.of drawings so he is not accepting this solution. Steps I have performed. Step1 has no results, step 2 showing text but we can not do(TXT2MTXT) in every block and every drawing. Please help me to resolve the issue. Thanks in Advance.
The TEXT STYLE uses SHX font instead of TRUETYPE font in your drawing. Hence it is not able to show Chinese characters which need a 'Bigfont' SHX file or a TRUETYLE font defined in your TEXT STYLE. As you can see in the example below, #1 is a TEXT object and its TEXT STYLE is using a TRUETYPE font. #2 is a TEXT object and its TEXT STYLE is using a SHX font.
Convert #2 to a MTEXT with TXT2MTXT we get #3. It automatically assign a CHINESE TRUETYPE font only to Chinese characters. After modification of TEXT STYLE definition of #2, Chinese characters is able to display properly in #4 as well. Let's check above objects and see their TEXT STYLE details. #1 Use TRUETYPE font.
#2 Use a simple SHX font #3 Once TEXT object has been converted into MTEXT, it uses TRUETYPE font to display Chinese characters automatically. #4 Modify TEXT STYLE and use Big Font to display Chinese Characters. So what you can do instead of using TXT2MTXT: 1. Change TEXT STYLE which shows??
Autocad Chinese Font Download For Windows 7
And use Truetype font. Change TEXT STYLE which shows??
And use big font. Alternatively, you can also convert all TEXT objects into MTEXT objects in one go with. Hello 3Wood, Thank you for your valuable time and information.
As mentioned above I have tried all steps, Step 4 working fine using big fonts. Here the problem is the user uses may drawing in daily and these drawing mostly containing all blocks user has to convert all blocks text styles. So user not accepting this solution. On another user computer working fine. I have copied all that fonts from working computer to this computer but no use still same error????? Please help me in this issue. Thanks & Regards Bhasker.
OK, try this ultimate solution. Save this code as a lsp file. You can name it as 'chstyle.lsp' (defun c:chstyle (/ st1 stname); By 3wood (while (if (not st1) (setq st1(tblnext 'style' T)) (setq st1(tblnext 'style')) ) (setq stname (cdr(assoc 2 st1))) (command 'style' stname 'romans.shx,gbcbig.shx' '0' '1' '0' 'N' 'N' 'N') ) ) 2. Type command APPLOAD and add 'chstyle.lsp' into 'Startup Suite' by pressing 'Content' button. Now you this add-on will be loaded automatically whenever you open a dwg file. Just ask the user type CHSTYLE in the command line to display all????
Autocad Fonts Download Free
It goes through all text styles and use 'gbcbig.shx' as the big font file for all of them. You can modify the lsp file and replace the.shx files as you preferred.
